View Large Image Product catalogue	Product name:	0.22um Syringe-driven Filters

	Model:	0.22um Syringe-driven Filters

	NO:	191435

	Price(FOB):	us$1.3 Order Order Contract Template

	Related Products:
		48 hole Serological plates 96 hole Serological plates 96 hole Serological plates 96 hole Serological plates

Detailed

Disposable Filtration Products series, including Syringe Driven Filters and Vacuum Filtration, are designed specifically for the filtration of culture media and organic solvents in research and industrial laboratories. They are purpose-built with features designed to bring the highest levels of performance and purity to your research. A variety of membrane types and membrane areas can be choosed that offer the wide applicability range for separation and purification of most liquid samples to meet different laboratory needs. The filtration products should be driven by syringes or vacuum pumps. All the products are manufactured with high quality material（PP） and by proficiented technique, which assure them can work under pressure and still hold integrity.

Housing Diameter (mm )

Filter Area
(cm²)

Housing Material

Process Volume (mL)

Hold-up Volume ( μL )

13.0

0.65

≤ 50

30.0

4.3

100

<100

13.0

0.65

≤ 50

30.0

4.3

100

<100

13.0

0.65

≤ 50

30.0

4.3

100

<100

13.0

0.65

≤ 50

30.0

4.3

100

<100

13.0

0.65

≤ 50

25.0

4.3

100

<100

Ordering Information
  ◎ Individually packed in peel-to-open paper/plastic blister pack
  ◎ Designed recycle paper package box for easy open and close or place
  ◎ Every package box is labeled with lot No.

Cat. No.	Membrane Material	Colour	Pore Size(μm)	Housing Diameter (mm)	Sterile	Qty. per b ox/ case
FMC201013	MCE	Yellow	0.22	13.0	Y	100/800
FMC201030			0.22	30.0	Y	45/360
FMC401013			0.45	13.0	Y	100/800
FMC401030			0.45	30.0	Y	45/360
FPV103013	PVDF	Blue	0.1	13.0	Y	100/800
FPV103030			0.1	30.0	Y	45/360
FPV203013			0.22	13.0	Y	100/800
FPV203030			0.22	30.0	Y	45/360
FPV403013			0.45	13.0	Y	100/800
FPV403030			0.45	30.0	Y	45/360
PTF205013	PTFE	White	0.22	13.0	Y	100/800
PTF205030			0.22	30.0	Y	45/360
PTF405013			0.45	13.0	Y	100/800
PTF405030			0.45	30.0	Y	45/360
PTF215013			0.22	13.0	Y	100/1000
PTF215030			0.22	30.0	Y	100/1000
PTF415013			0.45	13.0	Y	100/1000
PTF415030			0.45	30.0	Y	100/1000
FNY402013	Nylon	Pink	0.45	13.0	Y	100/800
FNY402030	Nylon	Pink	0.45	30.0	Y	45/360
FPE204013	PES	Green	0.22	13.0	Y	100/800
FPE204030			0.22	30.0	Y	45/360
FPE404013			0.45	13.0	Y	100/800
FPE404030			0.45	30.0	Y	45/360
